: Intel(R) 82577LM Gigabit Network Connection In a command prompt window, enter ipconfig /all, to the IP address of your PC interface, its description, and its MAC (physical) address. Step 1: Retrieve your PC interface addresses.įor this lab, you will need to retrieve your PC IP address and its network interface card (NIC) physical address, also called the MAC address.Ī. This analysis should help to clarify how packet headers are used to transport data to their destination. You will also look inside the frames captured for specific information. In Part 1 of this lab, you will ping another PC on the LAN and capture ICMP requests and replies in Wireshark. Instructions Part 1: Capture and Analyze Local ICMP Data in Wireshark If using a packet sniffer such as Wireshark is an issue, the instructor may wish to assign the lab as homework or perform a walk-through demonstration. It is recommended that permission be obtained before running Wireshark for this lab. Using a packet sniffer such as Wireshark may be considered a breach of the security policy of the school. Instructor Note: This lab assumes that the student is using a PC with internet access and can ping other PCs on the local area network. Additional PCs on a local-area network (LAN) will be used to reply to ping requests.In this lab, you will use Wireshark to capture ICMP data packet IP addresses and Ethernet frame MAC addresses. Wireshark is a useful tool for anyone working with networks and can be used with most labs in the CCNA courses for data analysis and troubleshooting. As data streams travel back and forth over the network, the sniffer “captures” each protocol data unit (PDU) and can decode and analyze its content according to the appropriate RFC or other specifications.
Wireshark is a software protocol analyzer, or “packet sniffer” application, used for network troubleshooting, analysis, software and protocol development, and education. Part 2: Capture and Analyze Remote ICMP Data in Wireshark Background / Scenario.Part 1: Capture and Analyze Local ICMP Data in Wireshark.3.7.10 Lab – Use Wireshark to View Network Traffic Topology
